TEINBRIDGE 5 Blade Propeller

Product Description

ON SALE TEINBRIDGE 5 Blade Propeller are high-performance marine screws, Nibral, designed for reduced vibration, improved thrust, and better fuel efficiency

General Specifications

• Material : High-quality Nibral (Nickel Aluminum Bronze) or Stainless Steel for durability.
• Blades : 5-blade configuration for smooth rotation and low vibration.
• Design : Often highly skewed (curved blades) for reduced noise and vibration, improved grip, and better performance, especially for faster vessels or heavy-duty use.
• Performance : Excellent throttle response, grip, and efficiency, with options for surface-piercing designs for high-speed applications.

Example Specific Propeller Specs (Vary widely)

• Example 1 (Industrial) : 610mm Diameter x 978mm Pitch (approx) x 5 Blades, Nibral, plastic reinforced edges for quietness, high torque.
• Example 2 (Trawler) : 3.2m Diameter, 5-blade Skewed Kaplan design, Nibral, used for high bollard pull.
• Example 3 (Leisure/Commercial) : 30″ Diameter x 38″ Pitch x 5 Blades, 3.00″ Bore, Right Hand (RH) rotation, Nibral.

Key Specification Terms

• Diameter : Propeller’s overall size (e.g., 30 inches).
• Pitch : How far the propeller moves forward in one revolution (e.g., 38 inches).
• Blades : Number of blades (e.g., 5).
• Bore : The size of the shaft hole (e.g., 3″ SAE).
• Rotation : Right Hand (RH) or Left Hand (LH).
• DAR (Blade Area %) : A measure of blade surface area (e.g., 92%).
